Avnet ADS5463 FPGA Module
AES-HSADC-EXP
AU$670.00
Out of stock
EXP HSADC MODULE
Avnet ADC module for FPGA
Purchase includes downloadable Documentations: User manual(Sch) , Design files, ...
ADS5463
Number of A/D Converters: 1
Number of Bits: 12
Sampling Rate (Per Second): 500M
Input Range: 2.2Vpp
Power (Typ) @ Conditions: 2.2W @ 500MSPS
Utilized IC / Part: ADS5463
EXP Interface
The Avnet EXP specification defines a 132-pin connector, with 24 power (twelve +2.5V and twelve +3.3V), 12 grounds, 84 user I/Os and 12 additional connector ground “blades”. EXP configuration implemented on all baseboards uses two connectors (Samtec part number QTE060-09-F-D-A) and EXP modules may be designed with either one or two EXP connectors (Samtec part number QSE-060-01-F-D-A).
